| Technical data | Chair type | Hydrulic Lift /Electromagnetic backrest Motor Driven Chair |
| | Power | 115V (+-10%), 50Hz, 5A. 220V available as special order |
| | Air Supply | 80 psi (clean, dry) |
| | Water Supply | 40 PSi |
| | Vacuum | Centralized |
| | Drain | Gravity drain (Can convert to vacuum drain) |
| | Maximum weight capacity | 600 lbs |
| | | |
| | | |
| Unit features | Handpieces tubing | 4 holes (4pcs) |
| | 3-way syringe | Doctor's tray (1pc) |
| | 3-way syringe - Assistant | 1 pc |
| | Clean water with bottle system | Dual Bottle System |
| | Rotating porcelain cuspidor bowl | Standard |
| | Operating Arm & Light | 10 bulb 60K LED sensor light with composite shield, 3 light colors ( Yellow, White, Natual) |
| | Foot Controller | Joystick controller (1 pc) |
| | High Suction (HVE) | Standard (2 pc) |
| | Low Suction (Saliva ejector) | Standard (1 pc) |
| | Dentist’s touch pad control | Standard |
| | Assistant Touch pad Control | Standard |
| | Armrest | Special design Double moverble armrest |
| | Double Articulating Headrest | Suitable for adult or children (Push Button) |
| | Foot Pedal | Standard Foot Pedal |
| | Auto return | Standard |
| | Upholstery | Eco friendly leatherette upholstery |
| | Water heater system | Standard |
| | City /bottle water option | Standard |
| | Programmable memory positions | Nine programmable positions with Digital display |
| | Doctor's Stool | AD040V |
| | AUX water connection for cavitron | Standard |
| | | |
| Additional Options | Built in Scalar | Optional |
| (additional cost will be added) | Build in Light curing unit | Optional |
| | Assistant's Stool | AD041V |
| | Fiberoptic tubing for 2 Handpieces | Optional (6 Holes) |
| | Electric Motor HP System | Optional |
| | Cavitron Tray | Optional |
| | European style (+$300) | Optional |
| | Monitor mount | Optional |
| | Delivery Mount | Side Right Handed ( This model can be switch to left hand mount with the assistance of a technician) |
| | | |
| Other details | standards and certifications | FDA , CE and ISO approved |
| | Warranty | 3 years on the chair motor and the frame one year on everything else parts warranty |
