GENORAY - Wall mount xray 2 year warranty on parts - DVAS-W
Earn up to 5,261 rewards points with this product!
Join today and start earning rewards points and unlock exclusive savings with US Dental Depot's Customer Loyalty Rewards Program
Description
XZEAL - Dental X-Ray Z70 DC- High Frecuency -Wall Mounted Arm Small 24in
X-Ray Units
# 124337 - Mfg # XZ026
Features:
Made with tubular steel and strong aluminum structure, XZeal Z70 AC allows smooth and accurate movements with a great mobility. The unit has been developed to produce X-rays of excellent quality with high image definition and lower exposure time for the patient.
XZeal Units provide the highest degree of safety for both operator and patient, complying with international quality and radiological safety standards.
Very light and counter balance arm prevents drifting.
Highlights:
* The Z70 AC offers radiographic performance with images with excellent contrast and hi definition and is compatible with film, PSP plate systems, and Dental Sensors.
* Built with light, strong, and resilient materials, the Z70 AC unit offers an arm with a very tight and accurate counter balance, which not only prevents drifting, but also allows for soft movements and precision that provides easy positioning to take radiographies.
* The Z70 AC provides clear radiographs with reduced exposure times, and provides the highest degree of safety for both operator and patient, complying with international quality and radiological safety standards.
With capacity of 70 kVp and 7 mA, the X-Ray head has lead covering. Made with tubular steel and a strong aluminum structure.
* The Z70 AC Wall model can be mounted on the wall with 16" double studs or a single 4"x4" stud. It is also ready for a push button installation or available an additional external control box to have it mounted outside the room.
Made in U.S.A. – 2 Years Warranty
Z70 DC Technical Data:
Power Input (Vac) – 110 V
High Voltage Range – 60kV – 70kV settable in step of 1kV
Tubehead Current Range – 4mA – 8mA settable in step of 1mA
Maximum Exposure Time – 4 sec.
Minimum Exposure Time – 10 msec.
Maximum Electrical output – 560 W to 70kV, 8mA
Duty Cycle – 1:15 automatic limit based on temperat.
Total X-Ray Filtration - > 2.5 mm Al equivalente at 70kV
Leakage Radiation @ 1m - < 0.88 mGy/h
Focal Spot (IEC 336) – 0.4 mm IEC
Available in 3 Arm Lengths:
15” Straight Arm Length has 61” Max. reach to Wall
24” Straight Arm Length has 70” Max. reach to Wall
33” Straight Arm Length has 79” Max. reach to Wall
