Description

AJ16 CLASSIC 200

■ Left/Right Swing Operatory Package

PRODUCT DESCRIPTION

■ AJ16 Luxury hydraulic chair with 3 programmable positions,

■ Double articulating headrest,

■ Swing up/down armrest,

■ Cast iron chair frame,

■ Cast aluminum backrest stand,

■ Cast aluminum base,

■ 60 degrees seat rotation, chair safety switch,

■ Wide backrest, Upgraded fiber leather,

■ One touchpad attached on armrest, Foot control

STANDARD FEATURES

■ Swing Classic dentist's control head with 3 auto H.P. control,

■ Individual water coolant controls,

■ Master handpiece air coolant adjustment,

■ Asepsis handpiece tubing,

■ Master on/off switch, 1 doctor syringe,

■ Wet/Dry foot control, Stainless steel tray with non-slip pad,

■ City/bottled water system, 5 ft umbilical,

■ Junction box with air/water filters, regulators, master shut-off valves,

■ Chair mounted swing rear assistant vacuum package,

■ Water outlet and air QD on assistant tray,

■ Solids collector, 2 HVE, 1SE, 1 syringe

■ Swing mount LED light with sensor control, 3 level intensity adjustment

PACKAGE INCLUDES

PART NUMBER

A091602

A0712003

A0502521

A0332303

A0603600

A11204

DESCRIPTION

A J 1 6 Hydraulic Chair
A J 1 6 Luxury hydraulic chair with cast aluminium backrest stan and chair base,
3 programmable positions, wide backrest, upgraded fiber leather

Classic 200 delivery system
Classic 200 Left/Right Swing Delivery System with 3 auto HP control,
bottled water system, Swing assistant vac pac with 2HVE, 1SE and 1 syringe.

Classic Swing mount dentist's control
Swing mount 3HP auto dentist's control, bottled water system, utility center and valves

Classic Swing mount assistant vacuum package
Chair mounted swing rear assistant vacuum package,
Water outlet and air QD on assistant tray,
2 HVE,1SE, 1 syringe

Swing mount Whale LED light
Swing mount touchless sensor Whale LED Dental Light with 24"light post
and swing compass arm

Chair Adapter D

PACKING DIMENSIONS (L*W*H)

Chair

Upholstery

Classic Dentist's Control

Swing mount assistant vacuum package

Classic Junction Box

Dental Light

47.6* 30.5*31.3"

50.4*25*8.9"

33.4*19.1* 12"
