Description

AJ18 Beyond 401

Left/Right Swing Operatory Package with cuspidor

PRODUCT DESCRIPTION

STANDARD FEATURES: AJ18 HYBRAULIC CHAIR :

■ 3 programmable positions

■ Double articulating headrest

■ Swing up/down iron armrest

■ Cast iron chair frame

■ Iron backrest stand

■ Cast aluminum base

■ Wide backrest, upgraded fiber leather

■ 60 degrees seat rotation, chair safety switch

■ One touchpad, Foot control

SWING Beyond DENTIST'S CONTROL HEAD & STANDARD TOUCHPAD :

■ Cast aluminium delivery head base, double pivot delivery head,

■ 3 auto H.P.control,

■ Individual water coolant controls,

■ Master handpiece air coolant adjustment,

■ Asepsis handpiece tubing,

MASTER ON/OFF SWITCH & 1 DOCTOR SYRINGE :

■ Wet/Dry foot control,

■ Stainless steel tray with non-slip pad,

■ City/bottled water system, 5 ft umbilical,

■ Junction box with air/water filters, regulators, master shut-off valves.

CHAIR MOUNTED SWING REAR CUSPIDOR AND ASSISTANT VACUUM PACKAGE :

■ Assistant touchpad, Water outlet and air QD on assistant tray,

■ Solids collector,2 HVE,1SE, 1 syringe

SWING MOUNT LED LIGHT :

■ With sensor control

■ 3 level intensity adjustment

PACKAGE INCLUDES

PART NUMBER

A091802

A0724015

A05025501

A0402400

A0602673

A11206

DESCRIPTION

A J 1 8 Hydraulic Chair
A J 1 8 wide backrest hydraulic chair with 3 programmable positions and fiber leather

Beyond 401 Delivery system with A J 1 8 Junction box
Beyond 401 Left/Right Swing Luxury Delivery System with 3 auto HP control,
Dentist touchpad, bottled water system, Swing mount side box,
Cuspidor and assistant vac pac with 2HVE, 1SE and 1 syringe, assistant touchpad.

Beyond Swing mount dentist's control with A J 1 8 Junction box
Swing Beyond dentist's control head, Standard touchpad,
Cast aluminium delivery head base, double pivot delivery head, 3 auto H.P.control,
1 doctor syringe, Wet/Dry foot control, Stainless steel tray, City/bottled water system,
5 ft umbilical, Junction box with valves

Classic 201/Beyond 401 Swing mount cuspidor and assistant vacuum package
Chair mounted swing rear cuspidor and assistant vacuum package, 2 HVE,1 SE, 1 syringe

Swing mount Amber II LED light
Swing mount touchless sensor Amber II LED Dental Light
with 24" light post and swing compass arm

Chair adapter E

PACKING DIMENSIONS (L*W*H)

Chair

Upholstery

Beyond Dentist's Control

Swing mount assistant vacuum package

Beyond Junction box

Dental Light

48.1*32.3*37.6"

50.4*9.3*25"

30.8*23.1*14.1"
